Diameter

￠80 mm – ￠1600mm

Thickness range

Galvanized steel

0.4 -1.3mm

Stainless steel

0.4-0.8mm

Aluminum

0.4-1.3mm

Strip width

Standard 137mm

0.4-1.0 mm

Standard 140mm

1.1-1.3 mm

Working speed

Max.40 m/min. depending on material

Cutting system

Slitting cutter

Weight

2900kg

Dimension

Main machine

3500*2100*1680mm

Run-out table

     2700*950*1200mm
